Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
37
Operation, Parts, and Instruction Manual
Table 8
360 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - For Two-Piece Plug Seals with
Standard Bonnets
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S41600 HT S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6
Seat & Guide
1”, 2” X 1” 1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN03D 1V6571XN05D 11A5315XN3D 11A5317XN4D
1/2 (12.7) 3/4 (19.1) 1V6572XN02D 1V6572XN06D 11A5316XN2D 11A5318XN4D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 1V6573XN04D 1V6573XN05D 11A5321XN2D 10A4438XN2D
1/2 (12.7) 3/4 (19.1) 1V6574XN01D 1V6574XN03D 10A4439XN4D 10A4611XN4D
1-1/2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN04D 1V6571XN09D 11A5315XN7D 11A5317XN7D
1/2 (12.7) 3/4 (19.1) 1V6572XN04D 1V6572XN09D 11A5316XN4D 11A5318XN3D
2, 3 x 2
(2)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 1V6575XN05D 1V6575XN06D 11A5324XN2D 11A5326XN2D
3/4 (19.1) 1-1/8 (28.6) 1V6576XN01D 1V6576XN03D 11A5325XN2D 11A5327XN1D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 1V6579XN09D 1V6579XN11D 11A5336XN3D 11A5337XN8D
3/4 (19.1) 1-1/2 (38.1) 1V6580XN01D 1V6580XN03D 11A5014XN1D 11A5338XN1D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 1V6581XN04D 1V6581XN05D 11A5341XN3D 11A5344XN2D
3/4 (19.1) 2 (50.8) 1V6582XN02D 1V6582XN07D 11A5342XN1D 11A5345XN4D
4 x 2-1/2
(2)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 1V6577XN04D 1V6577XN06D 11A5330XN2D 11A5332XN2D
3/4 (19.1) 1-1/2 (38.1) 1V6578XN01D 1V6578XN02D 11A5331XN2D 11A5333XN1D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 1V6584XN04D 1V6584XN06D 11A5350XN3D 21A5351XN6D
1 (25.4) 2 (50.8) 1V6585XN01D 1V6585XN02D 10A5107XN1D 20A0103XN1D
6 x 4
(2)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 1V6582XN01D 1V6582XN05D 11A5342XN4D 11A5345XN7D
1 (25.4) 2 (50.8) 360N6503N1D 360N6503N2D 360N6504N3D 360N6505N5D
NOTE: For 8 inch valves refer to Table 10.
* - Stem material is S20910.
1 - Valve plugs for 8 inch (203.2 mm) ports use one-piece plug seals constructed with a seal ring (Key 8) only, they do not use backup rings (Key 9)
or retaining rings (Key 10). These valves are also assembled with a style 1 extension bonnet as standard construction.
2 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
Parts Ordering
Whenever corresponding with Dyna-Flo about a 360 Series Control Valves, refer to the nameplate (Key 46) or name
tag (Key 47) for the serial number of the unit. Please order by the complete part number (as given in the part lists)
of each part required. NOTE: Not all the available replacement part numbers are shown in this manual, if you have
inquiries about parts that are not listed please contact your Dyna-Flo Sales Representative.
