Model 360/361 Control Valves
P-360M1019A
38
Operation, Parts, and Instruction Manual
Table 9
360 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - For Two-Piece Plug Seals with Style
1 Extension Bonnets
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S41600 HT S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6
Seat & Guide
1 1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN07D 1V6571XN06D 11A5315X13D 11A5317XN8D
1/2 (12.7) 3/4 (19.1) 1V6572XN03D 1V6572XN12D 11A5316XN3D 11A5318X14D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 1V6573XN07D 1V6573XN12D 11A5321XN4D 10A4438XN3D
1/2 (12.7) 3/4 (19.1) 1V6574XN05D 1V6574XN06D 10A4439XN5D 10A4611X11D
1-1/2x1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN10D 1V6571XN12D 11A5315X17D 11A5317XN5D
1/2 (12.7) 3/4 (19.1) 1V6572XN15D 1V6572XN19D 11A5316X14D 11A5318X13D
2
3x2
(2)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 1V6575XN18D 1V6575XN12D 11A5324XN4D 11A5326XN6D
3/4 (19.1) 1-1/8 (28.6) 1V6576XN11D 1V6576XN13D 11A5325X12D 11A5327X13D
2x1
(2)
1-5/16 (33.3) 1/2 (12.7) 3/4 (19.1) 1V6572XN03D 1V6572XN12D 11A5316XN3D 11A5318X14D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 1V6579XN08D 1V6579XN07D 11A5336X13D 11A5337XN6D
3/4 (19.1) 1-1/2 (38.1) 1V6580X101D 1V6580X103D 11A5014X11D 11A5338X11D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 1V6581XN07D 1V6581XN06D 11A5341X13D 11A5344XN5D
3/4 (19.1) 2 (50.8) 1V6582X102D 1V6582X107D 11A5342X11D 11A5345XN5D
4x2-1/2
(2)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 1V6577XN05D 1V6577XN12D 11A5330X12D 11A5332X20D
3/4 (19.1) 1-1/2 (38.1) 1V6578XN11D 1V6578XN12D 11A5331X12D 11A5333X11D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 1V6584XN05D 1V6584XN11D 11A5350X12D 21A5351XN5D
1 (25.4) 2 (50.8) 1V6585X101D 1V6585X102D 10A5107X11D 20A0103X11D
6x4
(2)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 1V6582X101D 1V6582X105D 11A5342X14D 11A5345X17D
1 (25.4) 2 (50.8) 360N650311D 360N650312D 360N650413D 360N650515D
* - Stem material is S20910.
1 - Valve plugs for 8 inch (203.2 mm) ports use one-piece plug seals constructed with a seal ring (Key 8) only, they do not use backup rings (Key 9)
or retaining rings (Key 10). These valves are also assembled with a style 1 extension bonnet as standard construction.
2 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
