Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
39
Operation, Parts, and Instruction Manual
Table 10
360 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - For Three-Piece Plug Seals without
Anti-Extrusion Rings (Standard Bonnets)
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S41600 HT S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6
Seat & Guide
1, 2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 20A4103XN5D 20A4103XN6D 360N1104N3D 20A4104XN2D
1/2 (12.7) 3/4 (19.1) 360N1112N1D 360N1112N2D 360N1113N3D 360N1114N5D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 20A6711XN3D 20A6711XN4D 360N5138N3D 22A5941XN2D
1/2 (12.7) 3/4 (19.1) 20A4150XN6D 20A4150XN2D 360N5147N3D 20A4151XN5D
1-1/2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 20A4103XN4D 20A4103XN7D 360N5104N3D 20A4104XN3D
1/2 (12.7) 3/4 (19.1) 360N5112N1D 360N5112N2D 360N5113N3D 360N5114N5D
2
3 x 2
(2)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 20A4097XN6D 20A4097N18D 360N2008N3D 20A4099N10D
3/4 (19.1) 1-1/8 (28.6) 20A4098XN6D 20A4098N18D 360N2181N3D 20A4100N10D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 20A5414XN6D 20A5414XN5D 360N3342N3D 22A3458XN2D
3/4 (19.1) 1-1/2 (38.1) 20A5342XN8D 20A5342XN2D 360N3351N3D 20A5344XN4D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 20A2641XN4D 20A2641N16D 360N4428N3D 21A0187XN2D
3/4 (19.1) 2 (50.8) 20A4194XN5D 20A4194XN2D 360N4437N3D 20A4197XN1D
4 x 2-1/2
(2)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 20A9533XN5D 20A9533XN6D 360N9312N3D 20A9534XN9D
3/4 (19.1) 1-1/2 (38.1) 20A4144XN1D 20A4144XN2D 360N9321N3D 20A4146XN1D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 20A2642XN5D 20A2642XN6D 360N6532N3D 21A8443XN3D
1 (25.4) 2 (50.8) 20A5621XN5D 20A5621XN6D 360N6541N3D 20A6706XN3D
6 x 4
(2)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 20A4194XN3D 20A4194XN7D 360N6498N3D 20A4197XN3D
1 (25.4) 2 (50.8) 360N6506N1D 360N6506N2D 360N6507N3D 360N6508N5D
8
(1)
8 (203.2)
3/4 (19.1) 2 (50.8) 21A5356XN1D 21A5356XN2D 21A5359XN1D 21A5362XN1D
1 (25.4) 2 (50.8) 21A5357XN1D 21A5357XN2D 21A5360XN1D 21A5363XN1D
3/4 (19.1) 3 (76.2) 21A5356XN1D 21A5356XN2D 21A5359XN1D 21A5362XN1D
1 (25.4) 3 (76.2) 21A5357XN1D 21A5357XN2D 21A5360XN1D 21A5363XN1D
* - Stem material is S20910.
1 - Valve plugs for 8 inch (203.2 mm) ports use one-piece plug seals constructed with a seal ring (Key 8) only, they do not use backup rings (Key 9)
or retaining rings (Key 10). 8” plug/stems are assembled with a style 1 extension bonnet as standard construction.
2 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
