Dyna-Flo 360 - Page 40

Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
Model 360/361 Control Valves
P-360M1019A
40
Operation, Parts, and Instruction Manual
Table 12
360 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - Anti-Cavitation 1 stage with
Standard Bonnets (without Anti-Extrusion Rings)
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S42000 HT
1 1-5/16 (33.3) 1/2 (12.7) 3/4 (19.1) 360N1001N8D
1-1/2 1-7/8 (47.6) 1/2 (12.7) 3/4 (19.1) 28A1002XN1D
2 2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 28A1003XN1D
3/4 (19.1) 1-1/8 (28.6) 28A1004XN1D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 28A1007XN1D
3/4 (19.1) 1-1/2 (38.1) 28A1008XN1D
4 x 2-1/2 2-7/8 (73)
1/2 (12.7) 1-1/2 (38.1) 28A1005XN1D
3/4 (19.1) 1-1/2 (38.1) 28A1006XN1D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 360N4002N8D
3/4 (19.1) 2 (50.8) 28A1010XN1D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 360N6000N8D
1 (25.4) 2 (50.8) 28A1013XN1D
6x4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 28A1010XN2D
3/4 (19.1) 2 (50.8) 28A1011XN2D
* - Stem material is S20910.
Table 11
360 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - Three-Piece Plug Seals with
Anti-Cavitation 2 Stage (Standard Bonnets)
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S42000 HT
S31600 / Alloy 6 Seat
& Guide
1 1 (25.4) 1/2 (12.7) 1 (25.4) 24A5265XN8D 24A5519XN2D
1-1/2 1-5/16 (33.3) 1/2 (12.7) 1-1/2 (38.1) 24A5266XN2D 24A5286XN2D
2 1-7/8 (47.6)
1/2 (12.7) 2 (50.8) 24A3038XN2D 24A5287XN2D
3/4 (19.1) 2 (50.8) 24A5550XN2D 24A5551XN2D
3 2-7/8 (73.0)
1/2 (12.7) 3 (76.2) 24A5269XN2D 24A5290XN2D
3/4 (19.1) 3 (76.2) 23A9452XN2D 24A5291XN2D
4 2-7/8 (73.0)
1/2 (12.7) 4 (101.6) 360N4462N8D 360N4463N5D
3/4 (19.1) 4 (101.6) 23A5818XN3D 24A5292XN5D
4 x 2
(2)
2-5/16 (58.7)
1/2 (12.7) 2-1/2 (63.5) 360N4454N8D 360N4455N5D
3/4 (19.1) 2-1/2 (63.5) 360N4458N8D 360N4459N5D
6 5-3/8 (136.5)
3/4 (19.1) 4 (101.6) 23A5803XN2D 24A5294XN2D
1 (25.4) 4 (101.6) 24A3028XN5D 24A5295XN3D
* - Stem material is S20910.
2 - Indicated Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
