Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
41
Operation, Parts, and Instruction Manual
Table 13
360 Globe Valve Plug / Stem* Assembly High Temperature (Keys 3, 4, & 5) - For Three-Piece Plug Seals with
Anti-Extrusion Rings (Standard Bonnets) - No Radius on Plug Seat
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6 Seat
& Guide
1, 2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N1106HN2D 360N1107HN3D 360N1108HN5D
1/2 (12.7) 3/4 (19.1) 360N1004HN2D 360N1116HN3D 360N1003HN5D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 360N5140HN2D 360N5141HN3D 360N5142HN5D
1/2 (12.7) 3/4 (19.1) 360N5149HN2D 360N5150HN3D 360N5151HN5D
1-1/2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N5106HN2D 360N5107HN3D 360N5108HN5D
1/2 (12.7) 3/4 (19.1) 360N5115HN2D 360N5116HN3D 360N5117HN5D
2
3 x 2
(2)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 360N2006HN2D 360N2175HN3D 360N2176HN5D
3/4 (19.1) 1-1/8 (28.6) 360N2183HN2D 360N2184HN3D 360N2185HN5D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 360N3344HN2D 360N3345HN3D 360N3346HN5D
3/4 (19.1) 1-1/2 (38.1) 360N3353HN2D 360N3354HN3D 360N3355HN5D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 360N4430HN2D 360N4431HN3D 360N4432HN5D
3/4 (19.1) 2 (50.8) 360N4439HN2D 360N4440HN3D 360N4441HN5D
4 x 2-1/2
(2)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 360N4314HN2D 360N4315HN3D 360N4316HN5D
3/4 (19.1) 1-1/2 (38.1) 360N4323HN2D 360N4324HN3D 360N4325HN5D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 360N6534HN2D 360N6535HN3D 360N6536HN5D
1 (25.4) 2 (50.8) 360N6543HN2D 360N6544HN3D 360N6545HN5D
6 x 4
(2)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 360N6500HN2D 360N6501HN3D 360N6502HN5D
1 (25.4) 2 (50.8) 360N6509HN2D 360N6510HN3D 360N6511HN5D
8
(1)
8 (203.2)
3/4 (19.1) 2 (50.8) 360N8593H12D 360N8594H13D 360N8595H15D
1 (25.4) 2 (50.8) 360N8599H12D 360N8600H13D 360N8601H15D
* - Stem material is S20910.
1 - 8” plug/stems are assembled with a style 1 extension bonnet as standard construction.
2 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
