Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
Model 360/361 Control Valves
P-360M1019A
Operation, Parts, and Instruction Manual
46
Table 18
361 Globe Valve Plug / Stem* Assembly High Temperature (Keys 3, 4, & 5) - For Double Piston Rings with
Style 1 Extension Bonnets
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6 Seat
& Guide
1, 2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N1500H12D 360N1501H13D 11A5319X13D
1/2 (12.7) 3/4 (19.1) 360N1503H12D 360N1504H13D 11A5320XN3D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 360N5506H12D 360N5507H13D 11A5322XN3D
1/2 (12.7) 3/4 (19.1) 360N5509H12D 360N5510H13D 11A5323XN3D
1-1/2 x 1
(2)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N5512H12D 360N5513H13D 11A5319XN7D
1/2 (12.7) 3/4 (19.1) 360N5515H12D 360N5516H13D 11A5320X11D
2
3 x 2
(2)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 360N2118H12D 360N2119H13D 11A5328XN3D
3/4 (19.1) 1-1/8 (28.6) 360N2121H12D 360N2122H13D 11A5329XN3D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 360N3148H12D 360N3149H13D 11A5339XN3D
3/4 (19.1) 1-1/2 (38.1) 360N3154H12D 360N3155H13D 11A5340X11D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 360N4172H12D 360N4173H13D 11A5347XN3D
3/4 (19.1) 2 (50.8) 360N4178H12D 360N4179H13D 11A5348X15D
4 x 2-1/2
(2)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 360N4142H12D 360N4143H13D 11A5334XN6D
3/4 (19.1) 1-1/2 (38.1) 360N4145H12D 360N4146H13D 11A5335X11D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 360N6208H12D 360N6209H13D 21A5353XN3D
1 (25.4) 2 (50.8) 360N6214H12D 360N6215H13D 21A5354X11D
6 x 4
(2)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 360N6196H12D 360N6197H13D 11A5348X19D
1 (25.4) 2 (50.8) 360N6503H12D 360N6504H13D 360N6505H15D
8
(1)
8 (203.2)
3/4 (19.1) 2 (50.8) 360N8238H12D 360N8239H13D 27A3965X11D
1 (25.4) 2 (50.8) 360N8241H12D 360N8242H13D 27A3966XN1D
* - Stem material is S20910.
1 - 8” plug/stems are assembled with a style 1 extension bonnet as standard construction.
2 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
