Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
Operation, Parts, and Instruction Manual
45
Table 17
361 Globe Valve Plug / Stem* Assembly High Temperature (Keys 3, 4, & 5) - For Double Piston Rings with
Standard Bonnets
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6 Seat
& Guide
1”, 2” X 1” 1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N1500HN2D 360N1501HN3D 11A5319XN2D
1/2 (12.7) 3/4 (19.1) 360N1503HN2D 360N1504HN3D 11A5320XN2D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 360N5506HN2D 360N5507HN3D 11A5322XN2D
1/2 (12.7) 3/4 (19.1) 360N5509HN2D 360N5510HN3D 11A5323XN2D
1-1/2 x 1
(1)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 360N5512HN2D 360N5513HN3D 11A5319XN5D
1/2 (12.7) 3/4 (19.1) 360N5515HN2D 360N5516HN3D 11A5320XN4D
2, 3 x 2
(1)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 360N2118HN2D 360N2119HN3D 11A5328XN2D
3/4 (19.1) 1-1/8 (28.6) 360N2121HN2D 360N2122HN3D 11A5329XN2D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 360N3148HN2D 360N3149HN3D 11A5339XN2D
3/4 (19.1) 1-1/2 (38.1) 360N3154HN2D 360N3155HN3D 11A5340XN1D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 360N4172HN2D 360N4173HN3D 360N4174HN5D
3/4 (19.1) 2 (50.8) 360N4178HN2D 360N4179HN3D 11A5347XN2D
4 x 2-1/2
(1)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 360N4142HN2D 360N4143HN3D 11A5334XN4D
3/4 (19.1) 1-1/2 (38.1) 360N4145HN2D 360N4146HN3D 11A5335XN2D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 360N6208HN2D 360N6209HN3D 21A5353XN4D
1 (25.4) 2 (50.8) 360N6214HN2D 360N6215HN3D 21A5354XN1D
6 x 4
(1)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 360N6196HN2D 360N6197HN3D 11A5348XN9D
1 (25.4) 2 (50.8) 360N6202HN2D 360N6203HN3D 360N6204HN5D
NOTE: For 8 inch valves refer to Table 18.
* - Stem material is S20910.
1 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
