Table 27
Reduced Trim Adapters (Keys 13 & 24)
- S31600/S31603 Dual Grade Material
Globe Body
Inch
Angle Body
Inch
Part
Seat Ring Adapter (Key 13) Cage Adapter (Key 24)
1-1/2 x 1 2x1 - 1U2218X316D
2x1 - 1U2262X316D 1U1207X316D
- 3 x 1-1/2 1U2304X316D 1U2302X316D
3 x 2 4 x 2 1U2346X316D 1U1246X316D
4 x 2-1/2 - 1U2396X316D 1U1251X316D
- LF2 (ASTM A350/A105 DUAL GRADE FORGED MATERIAL
Globe Body
Inch
Angle Body
Inch
Part
Seat Ring Adapter (Key 13) Cage Adapter (Key 24)
1-1/2 x 1 2x1 - 1U22182449D
2x1 - 1U22622449D 1U12072449D
- 3 x 1-1/2 1U23042449D 1U23022449D
3 x 2 4 x 2 1U23462201D 1U12462201D
4 x 2-1/2 - 1U23962201D 1U12512201D
Table 26
Cage (Key 19) - 361 Quick Opening - Double Piston Ring
Valve Size Inch Port Size Cage Material
Globe Body Inch (mm) S17400 H900 S17400 DH1150 S31600 / ENC
1, 1-1/2x1, 2x1 1-5/16 (33.3) 2U21503327D 2U21501150D 2U74034893D
1-1/2 1-7/8 (47.6) 2U21923327D 2U21921150D 2U72544893D
2, 3x2 2-5/16 (58.7) 2U22343327D 2U22341150D 2U74044893D
3 3-7/16 (87.3) 2U23183327D 2U23181150D 2U74064893D
4 4-3/8 (111.1) 2U23603327D 2U23601150D 2U74074893D
4x2-1/2 2-7/8 (73.0) 2U22763327D 2U22761150D 2U74054893D
6 7 (177.8) 2U50633327D 2U50631150D 2U80694893D
6x4 4-3/8 (111.1) 20A3249X01D 20A3249X02D 20A5469X01D
8
2 Inch Travel
8 (203.2) 2V37223327D 2V37221150D 2V37144893D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
