Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
51
Operation, Parts, and Instruction Manual
Table 28
Seat Ring (Keys 15) - For Standard Trim
Globe Body
Inch
Angle Body
Inch
Material
S41600 HT S31600 S31600 / Alloy 6 Hard Faced Seat
1, 2 x 1 1 1U22254617D 1U22253507D 1U22253910D
1-1/2 2 x 1 1U22194617D 1U22193507D 1U22193910D
1-1/2 x 1 2 1U22204617D 1U22203507D 1U22203910D
2, 3 x 2 4 x 2 1U22264617D 1U22263507D 1U22263910D
- 3 1U22274617D 1U22273507D 1U22273910D
3 4 1U22284617D 1U22283507D 1U22283910D
4 6 1U22294617D 1U22293309D 1U22293910D
6 - 1U50804617D 1U50803309D 1U50803910D
6 x 4 - 2V37194617D 2V37193507D 2V37204605D
8 - 20A3260X01D 20A3260X02D 20A3260X15D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
Table 29
Seat Ring (Keys 15) - For Anti-Cavitation Trim
Globe Body
Inch
Stage
Stage 1 Stage 2
S17400 H900
S31600 / Alloy 6
Hard Faced Seat & Bore
S17400 H900
S31600 / Alloy 6
Hard Faced Seat & Bore
1 23A7567X01D 23A7567X02D 24A5231X01D 24A5239X01D
1-1/2 23A7568X01D 23A7568X02D 24A5232X01D 24A5240X01D
2 23A7569X01D 23A7569X02D 24A3039X01D 24A5241X01D
3 24A3016X01D 24A3016X02D 360R338X09D 360R3001X5D
4 24A1135X01D 24A1135X02D 23A5813X01D 24A5244X01D
6 23A5820X03D 23A5820X01D 360R6015X9D 360R6016X5D
8 360R8000X9D 360R8001X3D 360R8002X9D 360R8004X5D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
