Model 360/361 Control Valves
P-360M1019A
52
Operation, Parts, and Instruction Manual
Table 31
Gaskets and Shim Repair Kits (Keys 12, 14, 20, 21, 22, & 25)
Valve Size inch
Gasket Kit
Globe Valve Angle Valve
1 1 RGASKETX31D
1-1/2 2 RGASKETX32D
1-1/2 x 1 2 x 1 RGASKETX24D
2 - RGASKETX33D
2 x 1 - RGASKETX25D
- 3 RGASKETX34D
- 3 x 1-1/2 RGASKETX26D
3 4 RGASKETX35D
3 x 2 4 x 2 RGASKETX27D
4 6 RGASKETX36D
4 x 2-1/2 - RGASKETX28D
6 - RGASKETX37D
6 x 4 - RGASKETX37D
8 - RGASKETX23D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
NOTE: Low-Noise III trim requires 2 bonnet gaskets (Key 22). Consult Dyna-Flo.
Table 30
Soft Seat Valve Parts (Keys 16, 17, & 18)
Valve Size inch Parts
Globe Valve Angle Valve
Disk Seat (S31600) Disk (PTFE) Disk Retainer (S31600)
1, 2 x 1 1 1V71023507D 1V71010624D 1V71003507D
1-1/2 2, 3 x 1-1/2 1V71053507D 1V71040624D 1V71033507D
1-1/2 x 1 2 x 1 1V71223507D 1V71010624D 1V71213507D
2, 3 x 2 4 x 2 1V71063507D 1V71070624D 1V71083507D
4 x 2-1/2 3 1V71113507D 1V71100624D 1V71093507D
3 - 1V71143507D 1V71130624D 1V71123507D
4 6 1V71173309D 1V71160624D 1V71153309D
6 - 1V71203309D 1V71190624D 1V71183309D
6 x 4 - 2V71243507D 1V71160624D 1V71233507D
8 20A4467X01D 20A4468X01D 10A4466X01D
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
