Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
53
Operation, Parts, and Instruction Manual
Table 32
Packing Parts (Keys 32, 33, 34, 39, 40, & 41)
PTFE Packing
Key # Description
Stem Diameter Inch (mm)
3/8 (9.5) 1/2 (12.7) 3/4 (19.1) 1 (25.4)
32
Packing Spring (S30400)
For Single Packing Only.
Part #
1F12543701D 1F12553701D 1F12563701D 1D58293701D
Qty.1111
33
Special Washer (S30400)
For Single Packing Only.
Part #
1F12523604D 1F12513604D 1F12503604D 1H98223604D
Qty.1111
34*
Packing Set
(Refer to Table 25 for Repair
Kits)
Part #
1R2900010DD 1R2902010DD 1R2904010DD 1R29060101D
Qty. Single 1111
Qty. Double 2222
39
Lantern Ring
(S31600/S31603 Dual Grade)
For Double PTFE Packing
Part #
DFX0000031D DFX0000001D DFX0000041D DFX0000051D
Qty.1111
Single Graphite Packing
Key # Description
Stem Diameter Inch (mm)
3/8 (9.5) 1/2 (12.7) 3/4 (19.1) 1 (25.4)
39
Lantern Ring
(S31600/S31603 Dual Grade)
Part #
DFX0000031D DFX0000021D DFX0000041D DFX0000051D
Qty.2122
39A
Lantern Ring
(S31600/S31603 Dual Grade)
Part # N/A
DFX0000001D
N/A N/A
Qty. N/A 1 N/A N/A
40 Graphite Filament Ring
Part #
1F3370X032D 1E3190X022D 1E3191X028D 1D7518X013D
Qty.2233
41 Graphite Ribbon Ring
Part #
1V3160X002D 1V3802X002D 1V2396X002D 1U6768X002D
Qty.2222
* - For 3/8 inch stems, remove a packing ring from the lower set for a total of 4 rings.
Table 33
Packing Repair Kits
Stem Diameter [Yoke
Boss Diameter] inches (mm)
Single Double
PTFE Graphite PTFE
3/8 (9.5) [2-1/8 (54)] RPACKX0001D RPACKXD010D RPACKXD004D
1/2 (12.7) [2-13/16 (71)] RPACKX0002D RPACKXD011D RPACKXD005D
3/4 (19.1) [3-9/16 (90)] RPACKX0003D RPACKXD012D RPACKXD006D
1 (25.4) [5 (127)] RPACKX0034D RPACKX0053D RPACKX0036D
To Next Page
