Dyna-Flo 360 - Page 43

Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
43
Operation, Parts, and Instruction Manual
Table 15
361 Globe Valve Plug / Stem* Assembly Standard Temperature (Keys 3, 4, & 5) - For Double Piston Rings with
Standard Bonnets
Valve Size Port Size Stem Diameter Travel Plug Material
Inch Inch (mm) Inch (mm) Inch (mm)
S41600 HT S31600
S31600 / Alloy 6
Seat
S31600 / Alloy 6
Seat & Guide
1”, 2” X 1” 1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN03D 1V6571XN05D 11A5315XN3D 11A5317XN4D
1/2 (12.7) 3/4 (19.1) 1V6572XN02D 1V6572XN06D 11A5316XN2D 11A5318XN4D
1-1/2 1-7/8 (47.6)
3/8 (9.5) 3/4 (19.1) 1V6573XN04D 1V6573XN05D 11A5321X02D 10A4438XN2D
1/2 (12.7) 3/4 (19.1) 1V6574XN01D 1V6574XN03D 10A4439XN4D 10A4611XN4D
1-1/2 x 1
(1)
1-5/16 (33.3)
3/8 (9.5) 3/4 (19.1) 1V6571XN04D 1V6571XN09D 11A5315XN7D 11A5317XN7D
1/2 (12.7) 3/4 (19.1) 1V6572XN04D 1V6572XN09D 11A5316XN4D 11A5318XN3D
2, 3 x 2
(1)
2-5/16 (58.7)
1/2 (12.7) 1-1/8 (28.6) 1V6575XN05D 1V6575XN06D 11A5324XN2D 11A5326XN2D
3/4 (19.1) 1-1/8 (28.6) 1V6576XN01D 1V6576XN03D 11A5325XN2D 11A5327XN3D
3 3-7/16 (87.3)
1/2 (12.7) 1-1/2 (38.1) 1V6579XN09D 1V6579XN11D 11A5336XN3D 11A5337XN8D
3/4 (19.1) 1-1/2 (38.1) 1V6580XN01D 1V6580XN03D 10A5104XN3D 11A5338XN1D
4 4-3/8 (111.1)
1/2 (12.7) 2 (50.8) 1V6581XN04D 1V6581XN05D 11A5341XN3D 11A5344XN2D
3/4 (19.1) 2 (50.8) 1V6582XN02D 1V6582XN07D 11A5342XN3D 11A5345XN4D
4 x 2-1/2
(1)
2-7/8 (73.0)
1/2 (12.7) 1-1/2 (38.1) 1V6577XN04D 1V6577XN06D 11A5330XN2D 11A5332XN2D
3/4 (19.1) 1-1/2 (38.1) 1V6578XN01D 1V6578XN02D 11A5331XN2D 11A5333XN2D
6 7 (177.8)
3/4 (19.1) 2 (50.8) 1V6584XN04D 1V6584XN06D 11A5350XN3D 21A5351XN6D
1 (25.4) 2 (50.8) 1V6585XN01D 1V6585XN02D 10A5107XN1D 20A0103XN1D
6 x 4
(1)
4-3/8 (111.1)
3/4 (19.1) 2 (50.8) 1V6582XN01D 1V6582XN05D 11A5342XN4D 11A5345XN7D
1 (25.4) 2 (50.8) 360N6202N1D 360N6202N2D 360N6203N3D 360N6204N5D
NOTE: For 8 inch valves refer to Table xx.
* - Stem material is S20910.
1 - Indicates Reduced Trim.
- All S31600 barstock is dual grade S31600/S31603 (316/316L).
