Model 360/361 Control Valves
Dyna-Flo Control Valve Services Ltd.
Phone: 780 • 469 • 4000 Toll Free: 1 • 866 • 396 • 2356 Fax: 780 • 469 • 4035 Website: www.dynafl o.com
P-360M1019A
55
MODEL NUMBERING SYSTEM
BODY STYLE
-
- GLOBE A ANGLE
VALVE SIZE
3
1 1 INCH 5 1-1/2 INCH 2 2 INCH 3 3 INCH
4 4 INCH 6 6 INCH 8 8 INCH E 10 X 8 INCH
ASME RATING
A
A 150 B 300 C 600
END CONNECTION
F
F RF J RTJ N NPT T BWE SCH 40
L BWE SCH 80 S SOCKET WELD
BODY MATERIAL
L
L LCC W WCC M CF8M 9 WC9
BOLTING
-
- B7 / 2H (STANDARD) A B7M / 2HM
B B8M / 8M K B7 / 2H FLUOROKOTE #1
L B7M / 2HM FLUOROKOTE #1
TRIM
2
1 TRIM D1 2 TRIM D2 4 TRIM D4 6 TRIM D6
C TRIM DC E TRIM DE J TRIM DJ 2H TRIM D2H
4H TRIM D4H 6H TRIM D6H 7H TRIM D7H 8H TRIM D8H
PORT SIZE
F
F FULL PORT R REDUCED PORT
PACKING STYLE
P
P SINGLE PTFE V-RING (PRESSURE) J DOUBLE PTFE V-RING (PRESSURE)
G SINGLE GRAPHITE (PRESSURE) V DOUBLE PTFE V-RING (VACUUM)
R DOUBLE PTFE V-RING (VACUUM / PRESSURE) L LIVE LOADED PTFE V-RING (PRESSURE)
T LIVE LOADED GRAPHITE (PRESSURE) D LIVE LOADED DUPLEX (PRESSURE)
K LIVE LOADED KALREZ
®
YOKE BOSS SIZE
2
1 2-1/8” (3/8” STEM) 2 2-13/16” (1/2” STEM) 3 3-9/16” (3/4” STEM) 5 5” (1” STEM)
PAINT
-
- DFPS-01 (STANDARD) 2 DFPS-02 (SEVERE SERVICE)
3 DFPS-03 (HIGH TEMPERATURE)
PISTON RING
G
G GRAPHITE PISTON RING H MULTIPLE GRAPHITE PISTON RINGS
CHARACTERISTIC
E
E EQUAL PERCENT L LINEAR Q QUICK OPENING
Z LOW-NOISE III A1 (LINEAR) Y LOW-NOISE III B3 (LINEAR)
C LOW-NOISE III C3 (LINEAR) 1 LOW-NOISE III D1 (LINEAR)
D LOW-NOISE III D3 (LINEAR)
CHARACTERISTIC (EXTENDED TRAVEL)
R MODIFIED EQUAL PERCENT S MODIFIED LINEAR
T MODIFIED QUICK OPENING W MODIFIED LOW-NOISE III A1 (LINEAR)
BONNET STYLE
S
S STANDARD T STANDARD TAPPED E EXTENSION STYLE 1
H EXTENSION STYLE 2
SHUT-OFF CLASS
2
2 CLASS II 3 CLASS III 4 CLASS IV
SAMPLE PART NUMBER: 361-3AFL-2FP2-GES2
361
