No. 60027, Issue 4. January 1998
4 Specifications 7
Steering Clutch Switch
Symbol Parameter Conditions Min Nom Max Units
V
LO
Low level switch voltage Microswitch closed 0 0.5 V
V
HI
High level switch voltage Microswitch open 3.5 5.0 V
Lighting Specification
Symbol Parameter Conditions Min Nom Max Units
Turn Indicator Outputs (each output)
V
TIO
Output Voltage 13.5 V regulator fitted 13.1 13.5 13.9 V
V
TIO
Output Voltage 13.5 V regulator not fitted V
BAT-1
V
BAT-0.1
V
BAT
V
I
TIO
Continuous Output 2.3 2.5 A
Current
Sidelight (Head / Tail Light) Output
V
SLO
Output Voltage 13.5 V regulator fitted 13.1 13.5 13.9 V
V
SLO
Output Voltage 13.5 V regulator not fitted V
BAT-1
V
BAT-0.1
V
BAT
V
I
SLO
Continuous Output 2.3 2.5 A
13.5 V Regulated Power Supply (SLM TÜV only)
V
REG
Output voltage Voltage In 18-32V 13.1 13.6 14.0 V
I
MAX
Maximum output Max. total lighting 7.5 9.0 11.0 A
current load (Note 1)
Note 1 The nominal lighting current corresponds to the sidelights and hazard
flashing. The supply will current limit at 9 A (nominal) to blow fuses. It is not
intended to be used at this level for any extended period of time.
