No. 60027, Issue 4. January 1998
7 Programming 27
7 Programming
Warning
Incorrect or inappropriate programming of a DX System may put the wheelchair
into a dangerous state.
Dynamic Controls accept no responsibility or liability for accidents caused by
incorrect programming.
This chapter must be read and understood before attempting to program a DX
System containing an SLM.
7.1 Introduction
The driving performance of an SLM is dependant on its programming. An SLM can
be adjusted for a particular application and the driving performance defined to suit
the requirements of an individual.
The SLM is programmed at the time of manufacture with factory settings defined
by the wheelchair manufacturer (OEM) and Dynamic Controls Ltd. Some
parameters may be modified later using the HHP, for individual user requirements.
If more than one type of wheelchair is to be used by the customer, each wheelchair
type may have its own set of optimum settings.
Non module specific programming of a DX System is contained in the PM and DX
Remote Installation Manuals. A servo steered DX System with one drive motor,
uses a single channel DX-PM-S, a two drive motor system a DX-PM, which are
programmed appropriately at the time of manufacture : see the PM Installation
Manual.
The DX Remote can access as many as five drive programs which are treated
differently in a servo steered DX System. The settings contained in these programs
must be selected with reference to this SLM Installation Manual. There are also
three lighting parameters that must be set up in the DX Remote program if lighting
functions are required.
