Dynamic DX Installation Manual

No. 60027, Issue 4. January 1998
5 Installation33
7.3 SLM PCD Parameters
Note Refer to section 7.4 Using the PCD for PCD operating instruction.
Refer to section 7.5 Using the HHP for HHP operating instructions.
7.3.1 Steering Profile Parameters
For each of the eight Steering Profiles (Program 1 - Program 8) there are 12 Steering
Profile parameters which define the Maximum Turning Speed : see section 7.2.
Parameter Purpose
Range (%)
Max Fwd Spd @ 25 Turn 35 - 100
Max Fwd Spd @ 50 Turn 25 - 100
Max Fwd Spd @ 75 Turn 20 - 100
Max Fwd Spd @ 100 Turn 15 - 100
Max Rev Spd @ 25 Turn 35 - 100
Max Rev Spd @ 50 Turn 25 - 100
Max Rev Spd @ 75 Turn 20 - 100
Max Rev Spd @ 100 Turn 15 - 100
Accessed by : Dealer
