No. 60027, Issue 4. January 1998
5 Installation 21
Thermal circuit breakers must be installed in the battery wiring to protect the
batteries, wiring loom and SLM from external short circuits. If the two batteries are
permanently wired together (single battery box), the best position for this circuit
breaker is between the two batteries. If the batteries are individually plugged
together (separate battery boxes), each battery requires a circuit breaker. Separate
lighting and driving circuit breakers are used, so that a fault which causes a circuit
breaker to operate, will not disable both lighting and driving.
Battery - has two connections to the SLM. This is to ensure that a break in one
battery will not disable driving or lights.
Battery Type
The DX System is designed to perform optimally with either Lead-Acid or Gel Cell
deep cycle batteries. Consult Dynamic Controls for other battery types. It is
recommended that two 12 V batteries with capacity greater than 20 A hours be
used.
5.4.5 SLM Connection to Lights
There are three lighting outputs : Pin 2 Side Lights -
Pin 3 Left Indicators -
Pin 4 Right Indicators -
The Side Light Output
This output is used to power head and tail lights. Multiple bulbs can be connected
to the output in parallel, as shown in the following diagram. The output is active
pull-down when the light is turned on.
The Left and Right Indicator Outputs
These outputs are also active pull-down when the light is turned on. Again, multiple
bulbs can be connected to each output.
