Dynamic DX Installation Manual

No. 60027, Issue 4. January 1998
8 Diagnostics55
8.3.2 Fault History
To view the Fault History :
1. Enter the PCD's Main Menu screen as described in the PCD Manual.
2. Select ‘Diagnose Faults’.
3. Select ‘Fault History’.
4. From the ‘Modules Attached’ menu, select ‘SLM’.
Below are listed the Fault History codes and probable causes of these faults. If
the suggested action does not remove the fault, contact a Dynamic Sales and
Service Centre (refer to section 12).
Message Possible Cause and Action
CPU / General
Fault
Cause : Internal Fault
Action: < Replace SLM.
< Consult an approved Dynamic Service Agent.
Hall / Overtemp /
ADC Fault
Cause: Internal Fault
Action: < Replace SLM.
< Consult an approved Dynamic Service Agent.
Relay / Precharge
Fault
Cause : 1. Short between a motor terminal and Battery +.
2. Internal Fault
Action: < Repair fault if found.
< Consult an approved Dynamic Service Agent.
Port Feedback
Fault
Cause: Internal Fault
Action: < Consult an approved Dynamic Service Agent.
Motor Summation
Fault
Cause : 1. External motor terminal short circuit.
2. A short circuit between a motor terminal
and: a battery terminal, a Position
Sense Pot terminal, or a clutch switch
terminal.
Action : < Check for the above and repair if
necessary.
