No. 60027, Issue 4. January 1998
7 Programming40
Motor Speed The time taken for the servo motor to travel the full
range from left lock to right lock, and visa
Range 20 - 5,100 ms versa.
(0.02 - 5.1 sec.) This is calibrated using the HHP.
Accessed by : Dealer / User
HHP calibrated
Motor Damping Factor The speed of response of the servo motor.
Range 0 - 100 % For slow motors this value should be low and for
Accessed by : DCL fast motors the damping should be high.
Warning An unsuitably high or low value can
make the wheelchair unstable.
Range (%)
Restrict Fwd Spd 25 % 60 - 100
Restrict Fwd Spd 50 % 40 - 100
Restrict Fwd Spd 75 % 20 - 100
Restrict Fwd Spd 100 % 0 - 100
Restrict Rev Spd 25 % 60 - 100
Restrict Rev Spd 50 % 40 - 100
Restrict Rev Spd 75 % 20 - 100
Restrict Rev Spd 100 % 0 - 100
Accessed by : Dealer / User The maximum forward and reverse speeds for four
HHP calibrated non-zero lock positions : 25, 50, 75 and 100 %
turning lock.
The physical restrictor plate fitted to the DX
Remote is calibrated with these parameters, using
the HHP.
If the DX Remote is replaced, these parameters
must be recalibrated.
Plate parameters are grouped and calibrated in one
operation of the HHP.
Parameter Purpose
