Message Fault and Possible Cause
Stall Timeout
Fault
Cause : The servo motor current has been at or close to
current limit for longer than the Stall Timeout
parameter value.
Action : < Turn the DX System off then on again. Allow
to cool down if necessary.
< Check that steering wheels can turn freely.
Battery Low
Cause : The battery voltage is less than 17 V
Action : < Recharge or replace battery.
Battery High
Cause : The battery voltage is greater than 32 V
Action : < Check that battery charger is operating
correctly.
< May be caused by continuous braking down a
hill at too higher speed. The problem will
occur when batteries are fully charged, fully
discharged or worn out.
Lighting SMPS
Fault
Cause : 1. A short circuit between the 13.4 V regulated
supply (if fitted) and battery + or -.
2. There is no power supplied to the lighting.
Action : < Check all lighting circuitry.
< Check wiring as per section 5.4.3 and 5.4.4.
Head Light Fault
Cause : The circuitry for the Side Lights (front and rear)
is faulty.
Action : < Check for an open circuit, or a short circuit
from the Side Lights to battery + or -.
< Check for blown headlight bulbs.
Left Indicator
Fault
Cause : The circuitry for the Left Indicator Light is
faulty.
Action : < Check for an open circuit, or a short circuit
from the Left Indicator Light to battery + or -
< Check for blown left indicator bulbs.
Right Indicator
Fault
Cause : The circuitry for the Right Indicator Light is
faulty.
Action : < Check for an open circuit, or a short circuit
from the Right Indicator Light to battery +
or -.
< Check for blown right indicator bulbs.
