CA 150 O150EN2
SAFETY DECALS, LOCATION/DESCRIPTION
Crush zone, articulation/
Drum. Maintain a safe dis-
tance from the crush zone.
Warning - hot surfaces in
the engine compartment.
Do not touch.
Warning - rotating engine
components. Keep your
hands at a safe distance from
the danger zone.
The operator is urgently
requested to read the safety
manual, and the operation
and maintenance instruc-
tions before using the
machine.
1.
2.
3.
4.
903424
903459
903423
903422
The articulation must be
interlocked when lifting.
Read the instruction manual.
5.
Lifting point
Diesel fuel
Tire pressure
110 kPa
16 psi
9.
8.
357587
991658
991990
908229
16.
10.
Battery
disconnector
11.
904835
Securing
point
14.
382751
7.
15.
Handbook
compartment
903425
Mass Kg
904870
12.
Lifting plate
Emergency exit
6.
Tires filled with ballast
(Optional).
Read the instruction manual.
17.
903985
Hydraulic
fluid
Biological
hydraulic
fluid
272372 904601
Alt. 1 Alt. 2
791277
13.
Sound Power
level
107
