7
CA 150 O150EN2
MACHINE AND ENGINE PLATES
Machine plate
PIN on frame
Fig. 3 Operator’s platform
1. Machine plate
Fig. 4 Front frame
1. PIN
Fig. 5 Engine
1. Engine plate
2. EPA sign (USA)
1
Engine plate
The PIN (1) of the machine is punched on the front right
edge of the forward frame beam.
The engine plate (1) is affixed to the right side of the
engine under the injection pump. The plate indicates the
type of engine, serial number and engine data. Please
state the engine serial number when ordering spares.
See also the Engine Manual.
1
1
Cummins Engine Company, Inc
Columbus, Indiana USA
47202-3005 www.Cummins.com
WARNING: Injury may result and warranty is voided
if fuel rate, rpm or altitude exceed published
maximum values for this model and application.
Timing-BTDC 8 degrees
This engine conforms to YYYY U.S. EPA and California
regulations for large non-road compression ignition
engines as applicable. This engine is certified to
operate on diesel fuel.
Valve Lash Intake 0.014in/0.35mm
(cold engine) Exhaust 0.020in/0.50mm
Fuel rate at rated HP/kW 61mm3/st
S.O. # SO94678
Made in Japan 6204-81-2411
Important Engine Information
Model B3.3 ESN 68006011
Gross rated HP/kW 80 /60 at 2200 rpm
Low Idle RPM 800 R PM
Fuel Rating FR30004
CPL
Displacement: 3.261L/1991
Displacement: 3.261L/1991
European Approval Number:
e11*97/68CA*00/000*0069*00
Date of Manufacture 20010219
The machine plate (1) is affixed on the front left side of
the frame, by the steering joint. The plate shows the
manufacturer’s name and address, type of machine,
product identification number (PIN), weight in working
order, engine power and year of manufacture (the year
of manufacture is not specified if the machine is
delivered outside the EU).
Please state the roller PIN when ordering spares.
