Dynapac DR6X - Noise and Vibration Data; Noise Data

Drive
Engine manufacturer Honda
Type GXR 120
Cooling Air
Number of cylinders 1
Displacement 121
cm
3
Rated power SAE J 1349 2.8
(3.8)
kW
(hp)
Rated speed 4200
min
-1
Exciter system
Drive system mechanical
Frequency 10 - 11.8
(600 - 708)
Hz
(bpm)
Impact force 15
(3372)
kN
(lbf)
Filling capacities
Fuel (gasoline) 3.0
(0.8)
l
(gal us)
2.1 Noise and vibration data
The following noise and vibration data were determined in accord-
ance with the following guidelines under equipment specific condi-
tions and by using harmonized standards:
n EU Machine Directive edition 2006/42/EU
n Noise Emission Directive 2000/14/EU, Noise Protection Direc-
tive 2003/10/EU
n V
ibration Protection Directive 2002/44/EU
During operation these values may vary because of the prevailing
operating conditions.
2.1.1
Noise data
L
pA
= 93 dB(A), determined acc. to ISO 11201 and EN 500.Sound pressure level at the opera-
tor's stand
Technical data – Noise and vibration data
DR6X
13
