Dynapac DR6X - Semi-Annually; Changing the Engine Oil

8.8 Semi-annually
8.8.1
Changing the engine oil
NOTICE!
Danger of engine damage!
– Change the oil only with the engine at oper-
ating temperature.
–
Use only oil of the permitted specification
Ä Chapter 8.2.1 „Engine oil“ on page 65.
– Filling quantity:
Ä Chapter 8.3 „List of fuels and
lubricants“ on page 67
Protective equipment:
n
W
orking clothes
n
Protective gloves
1.
Park the machine in secured condition Ä Chapter 6.4
„Parking the machine in secured condition“ on page 55.
2. Park the machine so that the tamper foot is in horizontal posi-
tion.
3.
WARNING!
Danger of burning on hot components!
– Wear your personal protective equipment
(protective gloves, protective clothing).
–
Avoid touching hot components.
Clean the area around oil dipstick (1) and drain plug (3).
4. Unscrew the oil dipstick.
5. Unscrew the drain plug and collect any oil running out.
6. Clean the oil drain plug and screw it back in with a new seal
ring (2).
7. Fill in fresh oil up to the bottom edge of the filler bore.
8. Push the oil dipstick (1) back in.
9. Check for leaks after a short test run.
10. Check the oil level on the dipstick, correct if necessary
.
11. Dispose of oil in an environmentally friendly way
.
Fig. 58
Fig. 59
Maintenance – Semi-annually
DR6X
75
