4. Unscrew the screws (2) and remove the engine stop switch
(1).
5. Unscrew the fuel valve (2) and remove the seal (1).
6. Clean the screen and check for damage.
7. Replace the fuel valve if damaged.
8. Assemble the fuel valve with a new seal
9. Assemble the engine stop switch (1) with screws (2).
10. Connect the fuel hose with the hose clamp (1) to the fuel
valve (2).
Fig. 87
Fig. 88
Fig. 89
Fig. 90
Maintenance – Annually
DR6X
86
