Nominal values:
Idle speed
1850 to 2000 min
-1
Maximum engine speed
3850 to 4200 min
-1
1. Start the engine and run it warm for approx. 15 minutes.
2. Run the machine on ground that can be compacted.
3. Set the throttle lever to position “MIN”.
4. After approx. 30 to 40 seconds read the idle speed from the
engine rpm-meter
.
5. Set the throttle lever to “MAX” position.
6. After approx. 30 to 40 seconds read the max. speed from the
engine rpm-meter
.
7. If necessary
, adjust the idle speed or maximum speed as
required.
Fig. 99
Fig. 100
Fig. 101
Maintenance – Annually
DR6X
90
