7. Fill in fresh oil up to the bottom edge of the filler bore.
8. Clean the filling plug and screw it back in with a new seal
ring.
10. Check the oil level in the inspection glass, correct if neces-
sary
.
The upper edge of the inspection glass
equals the bottom edge of the oil filling bore.
11. Dispose of oil in line with environmental regulations.
Fig. 113
Fig. 114
Maintenance – Annually
DR6X
95
