EFIS Operation
5-8 FlightDEK-D180 Pilot’s User Guide
• In the CLOCK > FORMAT menu, press LC/ZU to change between local and Zulu time display on the EFIS
page. Press 12/24 to change between standard and military time display on the EFIS page
SHOW/HIDE DISPLAY ITEMS
In the EFIS > SETUP > CLUTTR menu, you can turn on or off almost every item displayed on the EFIS page. As with
all other menu items, these options are abbreviated to commands containing 6 letters or fewer. Pressing a button
corresponding to one of these options turns the respective onscreen item on or off. The following table summarizes the
display item abbreviations and their function.
Abbreviation Display Item Function
ALTBAR Altimeter Bar Toggles the display of the graphical altitude tape.
ALTDIG Altimeter Digital Toggles the display of the digital altitude window.
IASBAR Indicated Airspeed Bar Toggles the display of the graphical airspeed tape.
IASDIG Indicated Airspeed Digital Toggles the display of the digital airspeed window.
HDG Heading Toggles the display of the heading tape and digital display.
BALL Slip/skid Ball Toggles the display of the slip/skid ball and associated center markers.
TURNRT Turn Rate Toggles the display of the turn rate indicator and associated scale markers.
AOABAR AOA Bar
Toggles the display of the angle of attack indicator. The AOA indicator requires the
use of a Dynon heated or unheated AOA probe.
CLOCK Clock
Toggles the display of the clock. Setting Zulu/local and 12/24 hour time is done in
the EFIS > SETUP > CLOCK menu.
BARO Altimeter setting
Toggles the display of the current altimeter setting (also known as the Kollsman
setting). This display is not required to set the altimeter setting. While in the EFIS >
BARO menu, a separate value-setting box appears, allowing adjustments to be
made.
