4. AVAILABLE PAGES
The EFIS main pages use various tapes, digital displays, and other indicators overlaid on an artificial horizon. On the 2/3
and full-screen pages, you may also display up to two “info items” on the left and right side of the main page. HSI pages
use text and a DG style compass by itself or overlaid with lines and arrows of different colors.
Note: HSI pages use data that is obtained from a source external to the FlightDEK-D180. Refer to the FlightDEK-
D180 Installation Guide for a list of compatible equipment.
The EMS pages use various combinations of circular gauges, vertical and horizontal bars, tic marks, and text to display
EMS data. Appropriate units of measurement accompany their respective values. Color indicators (green, yellow, and
red) are used to denote normal and abnormal operational ranges.
FlightDEK-D180 Pilot’s User Guide 4-1
Both the EMS Main Pages and the EMS Auxiliary Page allow for “info items,” user-configurable elements such as
vertical info bars, contact input readouts, flaps/trim indication, and text-only items. Vertical info bars can display volts,
amps, fuel pressure, carburetor air temperature, coolant temp/pressure, and outside air temperature. Contact input
readouts can display discrete data (e.g., open/closed, on/off, etc.). Flaps and trim displays display icons indicating the
absolute position of the flaps and trim. Vertical info bars, contacts, flaps/trim indicators, and text-only items are defined
at time of installation and instrument setup. Text info items include fuel economy, engine timers, and times. For more
information on configuring this display (as well as info items on the EMS Main Page), see the Info Item Configuration
section on page 10-6. Menu, Checklist, and EFIS pages may be displayed and are described in the following sections.
