• Ambient temperature range: from +0...+40 °C(+0 ...+35 °C for 240 kVA and
360 kVA PF 0.9 models).
• Recommended operating range for VRLA batteries: +20...25 °C.
• Maximum relative humidity: 95%, non-condensing.
• Recommended relative humidity range: 20 - 60 %.
You must arrange ventilation of the UPS room. Sufficient amount of air cooling is
needed to keep the maximum room temperature rise at desired level.
• To limit the temperature rise to a maximum of +5 °C, the required airflow is
600 m
3
/h per 1 kW of losses.
• To limit the temperature rise to a maximum of +10 °C, the required airflow is
300 m
3
/h per 1 kW of losses.
An ambient temperature from +20 to +25 °C is recommended to achieve a long
life of the UPS and batteries. The cooling air entering the UPS must not exceed
+40 °C. Avoid high ambient temperature, moisture, and humidity.
For ventilation requirements, see 93PM-G2 heat rejection in the following table.
Table 7: Air conditioning or ventilation requirements during full load operation
UPS model Heat rejection
(BTU/h x 1,000)
Heat rejection
[kW]
93PM G2 50(200) 6,9 2,0
93PM G2 100(200) 13,8 4,1
93PM G2 150(200) 20,2 5,9
93PM G2 200(200) 26,6 7,8
93PM G2 240(240) 0.9 PF 30,7 9,0
93PM G2 50(300) 6,9 2,0
93PM G2 100(300) 13,8 4,1
93PM G2 150(300) 20,2 5,9
93PM G2 200(300) 26,6 7,8
93PM G2 250(300) 32,8 9,6
93PM G2 300(300) 38,9 11,4
93PM G2 360(360) 0.9PF 47,3 13,9
