Eaton 9PX Lithium-Ion - UPS LCD Indicator Meanings

6 Eaton 9PX Lithium-Ion P-164001006—Rev 01
Online mode
indicator (green)
Fault
indicator (red)
Online mode
100%
19min
1EBM
100%
2.4kW
3.0kVA
Efficiency: 94 %
Escape Up Down Enter On/Off
button
Battery mode
indicator (orange)
Bypass mode
indicator (orange)
Indicator Status Description
Green
On
The UPS is operating normally on Online
or on High Efficiency mode.
Orange
On The UPS is on Battery mode.
Orange
On The UPS is on Bypass mode.
Red
On
The UPS has an active alarm or fault.
22..55 LLCCDD DDeessccrriippttiioonn
Operation status
Load/equipment status
Online mode
100%
19min
1EBM
100%
2.4kW
3.0kVA
Efficiency: 94%
Battery status
Efciency and load group information
LCD Description
