Eaton 9PX Lithium-Ion User Manual

Eaton 9PX Lithium-Ion P-164001006—Rev 01 19
Figure 8. 9PXEBM Tower Mount Connections
9PXEBM48
9PXEBM72
Battery Comm
Battery Comm
Battery Comm
Battery Comm
UPS
EBM Communications wiring
EBM 1 EBM 2 EBM 3
EBM 4
NOTE The EBM communication wiring connections are directional and must be connected in
the correct sequence to ensure proper detection, regulation and lifecycle monitoring of
the integrated battery management system (BMS).
33..77 DDeetteeccttiinngg ootthheerr AAcccceessssoorriieess
Tip If you ordered other UPS accessories, refer to specific user manuals to check the connection to the UPS.
Detecting other Accessories
