Removal and Disassembly
9
Removal and Disassembly
How to Remove the Companion Flanges or Yokes
Special Instructions
None
Special Tools
• Typical service tools
Procedure -
1. Brace against the yoke or flange on each shaft and use a
large breaker bar to remove the elastic stop nut from each
shaft.
2. Remove the washer and flange or yoke from each shaft.
Note: If a special tool is not available, the stop nuts may be
removed by putting the transmission in direct gear,
installing a breaker bar on the stop nut of both input
and output shaft and removing the nuts by bracing
them against each other.
