Tools
6
Tool Reference
Some illustrations in this manual show the use of specialized maintenance tools. These tools are recommended for transmission
repair as they make repair easier, faster, and prevent costly damage to such critical parts as bearings and sleeves.
Listed below are charts which list these specialized tools, the tool name and how it can be obtained.
Specialty Tool Manufacturers
Below are the addresses and phone numbers of the companies that make tools specifically for Eaton®Fuller® transmissions:
G and W Tool Company
1105 E. Louisville, Broken Arrow, OK 74012-5724, Phone: 800-247-5882, or 918-258-6881
Great Lakes Tool
8530 M-89, Richland, MI 49083, Phone: 800-877-9618, or 269-629-9628
General Tools
Tool Purpose
0-100 lbs.ft. 1/2" drive Torque Wrench General torquing of fasteners.
0-600 lbs.ft. 3/4" or 1" drive Torque Wrench Torquing of output nut.
Snap Ring Pliers - large standard external To remove snap rings at the auxiliary drive gear, input shaft
bearing, and countershaft.
Rolling Head (Crow’s foot) prybar To remove the auxiliary drive gear bearing.
Aftermarket Tools
Tool Purpose Eaton Part Number
Seal Driver Kit To install seal K-2413
Special Tools
Reference Number Tool Purpose G and W Tool Number Great Lakes Tool Num-
ber
Seal Driver Used to install the oil
seals in the front and
rear bearing cover
housings.
G-112
Bearing Driver Used to install the input
shaft and output shaft
bearings.
Bearing Driver Used to install the
countershaft bearings.
