Eaton Fuller AT-1202 - How to Remove the Rear Plate from the Front Case

Removal and Disassembly
10
How to Remove the Rear Plate from the Front Case
Special Instructions
None
Special Tools
• Typical service tools
Procedure -
1. Loosen the jam nut and turn the rod end from the end of the
shift bar.
2. Turn out the 19 capscrews attaching the rear plate to the
front case.
