Eaton Fuller AT-1202 - How to Remove the Shifting Control Assembly Without Air

Removal and Disassembly
15
Removal and Disassembly
How to Remove the Shifting Control Assembly Without Air
Special Instructions
None
Special Tools
• Typical service tools
1. Eye Rod end
2. Nut
3. Yoke Bar
4. Spacer
5. Shift Yoke
6. Lockscrew
7. Gasket
8. Shift Cylinder
9. Plug
10. Capscrew
11. Spring
12. Steel Ball
13. NLA-Spacer
1
2
3
4
5
13
13
7
8
10
10
9
11
11
6
12
12
