Eaton Fuller AT-1202 - Page 15

Removal and Disassembly
14
4. Remove the yoke from the sliding clutch and remove the
sliding clutch from the splines of the output shaft.
5. Turn out the four capscrews attaching the shift bar housing
to the rear plate and remove the housing.l
6. Tip the housing to remove the tension spring and ball.
