Matrix Telecom Inverter System
34
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
STS Status Menu Description
Address STS module location
Serial No Serial number of installed STS module
OPV Output voltage of STS module
OPI Output current of STS module
OPF Output frequency of STS module
OPP Output power of STS module
Mains AC Volt Voltage of Mains AC connected to STS module
Main AC Freq Frequency of Mains AC connected to STS module
INV AC Volt Voltage of Inverter AC connected to STS module
INV AC Freq Frequency of Inverter AC connected to STS module
MBS Position Current MBS position (IBP /ISS/Normal/MSS/MBP)
Running Mode STS running mode (Inverter/mains/standby/power on)
Default Volt STS default output voltage (V)
Default Freq STS default output frequency (Hz)
Power Used Load level (%)
Temperature STS internal temperature (ºC)
Run Time STS total running time in (hours)
Priority STS output priority (On-line/Off-line)
HW Rev Hardware version of STS module
SW Rev Software version of STS module
Controller Menu Description
Hardware Version Hardware version of controller module
Firmware Version Software version of controller module
Input vol DC input voltage of controller module (V)
Temperature Controller temperature (ºC)
