Parameter Programming

Inverter Parameter Settings

Parameter Setting Option

Output volt Inverter output voltage

For 230Vac output:

1) 208 Vac; 2) 220 Vac; 3) 230 Vac; 4) 240 Vac

For 110Vac output:

1) 110Vac; 2) 115Vac; 3)120Vac

Output Freq Inverter output frequency: 50Hz or 60Hz

OPV HL: High loss of

inverter output voltage

For Output volt = 208V, adjustable between 220V and 240V

For Output volt = 220V, adjustable between 233V and 252V

For Output volt = 230V, adjustable between 244V and 264V

For Output volt = 240V, adjustable between 254V and 276V

For Output volt = 110V, adjustable between 117V and 127V

For Output volt = 115V, adjustable between 122V and 132V

For Output volt = 120V, adjustable between 127V and 138V

OPV LL: Low loss of

inverter output voltage

For Output volt = 208V, adjustable between 176V and 198V

For Output volt = 220V, adjustable between 176V and 209V

For Output volt = 230V, adjustable between 185V and 218V

For Output volt = 240V, adjustable between 193V and 228V

For Output volt = 110V, adjustable between 89V and 105V

For Output volt = 115V, adjustable between 93V and 110V

For Output volt = 120V, adjustable between 100V and 114V

IPV LVSD The maximum input voltage for inverter normal operation:

Adjustable between 39V and 44V

IPV HVSD The minimum input voltage for inverter normal operation:

Adjustable between 59V to 61V

Power Limited Inverter output power capacity:

Adjustable between 50% and 100%

Fan Speed Fan speed level of inverter module:

Selectable at 1) Normal and 2) Full

Inverter On/off 1. All > On/Off

2. Single > select Inverter number > select On/Off.
