Appendix C
Default Values
Copyright © 2008-2010 Eaton Corporation. All Rights Reserved.
IPN 997-00012-68D February 2010
71
Appendix C
Default Values
Controller Default Values
STS priority on-line
230Vac System Default Values (INV-4810E or INV-4815E inverters)
The following default values apply to systems with INV-4810E or INV-4815E inverter modules.
Mains high loss volt: 264V
Mains low loss volt 185V
Inverter input highloss volt for STS 264V
Inverter input lowloss volt for STS 185V
Inverter output highloss volt 264V
Inverter output lowloss volt 185V
Inverter shut down due to low input volt 40V
Inverter shut down due to high input volt 60V
Inverter output volt 230V
Inverter output volt frequency 50Hz
Inverter output power limit 100%
120Vac System Default Values (INV-4810 or INV-4815 inverters)
The following default values apply to systems with INV-4810 or INV-4815 inverter modules.
Mains high loss volt 138V
Mains low loss volt 100V
Inverter input highloss volt for STS 138V
Inverter input lowloss volt for STS 100V
Inverter output highloss volt 138V
Inverter output lowloss volt 100V
Inverter shut down due to low input volt 40V
Inverter shut down due to high input volt 60V
Inverter output volt 120V
Inverter output volt frequency 60Hz
Inverter output power limit 100%
