UPS SETUP
EATON Powerware
®
9355 UPS (20/30 kVA) Installation and Operation Manual S 164201626 Rev B www.powerware.com
10
Removing and Replacing the Front Doors
To remove and replace the UPS or Options Cabinet front door, see the following
section. To remove and replace the Extended Battery Cabinet (EBC) front door, see
“EBC Front Door” on page 11.
UPS or Options Cabinet Front Door
To remove the UPS or Options Cabinet front door:
1. Press and rotate the latches 90° to open the front door (rotate the left latch
clockwise and the right latch counter-clockwise). See Figure 2.
2. Lift the door up and off the cabinet.
To replace the door:
1. Insert the door notches into the slots on the bottom of the cabinet.
2. Secure the door latches.
Figure 2. Removing the UPS Front Door
