XS series operating manual
XS user manual v0.55 - 107 -
Dielectric strength test mode, 2 outputs setup
Refer to section related to the board jumpers setup. This setup is the factory default setup.
The pin 2 of the rear panel connector gives the value of the measured high voltage (V1) :
from 0 to 10 volts for 0 to 5000 VAC
from 0 to 10 volts for 0 to 6000 VDC
The pin 1 of the rear connector gives the value of the leakage current (V2) :
from 0 to 10 for 0.00mA to 9.99 mA
Test voltages and leakage current are given by the following formulas:
HTVAC = (V1/10) x 5000 volts
HTVDC = (V1/10) x 6000 volts
I = (V2/10) x Imax.
Imax = 9.99mA for SXS, DXS and RXS50
Imax = 99.9mA for SXS, DXS and RXS500
Accuracy of the 0-10 volts output voltage compared to the display : ±(0.1% + 5 mV)
Dielectric strength test mode, 1 output + 1 input setup
Refer to section related to the board jumpers setup.
This setup is operating only in the MANUAL mode
Select HIPOT function
Select PARAM
On <page2>, on the line TIMER : select the MANUAL mode
The pin 2 of the rear panel connector gives the value of the measured high voltage (V1) :
from 0 to 10 volts for 0 to 5000 VAC
from 0 to 10 volts for 0 to 6000 VDC
Test voltages are given by the following formulas:
HTVAC = (V1/10) x 5000 volts
HTVDC = (V1/10) x 6000 volts
Accuracy of the 0-10 volts output voltage compared to the display : ±(0.1% + 5 mV)
The pin 1 of the rear panel connector is an input which can receive voltages between 0
and 10 VDC for output high voltages from 0 to the maximum value displayed on the parameter
line:
VOLTAGE:x.xx VAC.
If the input voltage is higher than 10 V +5%, the following message is displayed :
[LIMIT ERROR]
Accuracy of the output high voltage compared to the input voltage :
±(1% + 20 volts) for a leakage current < 100uA
There is no automatic adjustment of the output voltage according to the load.
