XS series operating manual
XS user manual v0.55 - 117 -
The maximum number of commands by message is 15.
NOTE :be careful not to put together standardised commands with other ones.
When a event like transmission error,end of test, safety loop open, ...,occurs during the measurement
, the controller could be informed by a SRQ.
To activate this function, you must send a SRQ command just after the initialization of the unit.
On event, you could read the internal registers of the IEEE controler ( STB,SRE,...) to get more
precise reasons why.
If the message is not recognized by the unit, the error message <DIALOG ERROR : 1> is displayed
If the code is out of context, the error message <DIALOG ERROR: 2> is displayed
(special code for a function when the function was not selected or numerical value out of range)
List of the ETHERNET commands
The command set for the IEEE-488 interface is the same as the RS232. It is described with a lot of
details in the next subject RS232 interface.
