Eazao Zero - Printer Side View; Electric Putter

PRODUCT OVERVIEW
2.3 Printer Side View.
1
2
3
1. Lock Nut
2. Z-Axis Limit Bolt
3. Thumbwheels
2.4 Electric Putter.
2
3
1
4 5 6
7
8
10
9
1. 57 Stepper
2. Threaded Push Rod
3. Anti-Rotation Flange
4. Reducer
5. Cartridge Fixing Ring
6. Cartridge
7. Fixed Screw
8. Thrust Block
9. Finger Screw Nut
10. Rubber Piston
* As shown in the figure above, the electric putter stroke is at the maximum position.
