P.27
PM10U
EBARA
CORPORATION
The output signal (pin No. 5-13) is no-voltage relay contact outputs. The contact capacity is
AC230V/0.2A and DC30V/0.3A.
The output signal (pin No. 6, 7-14) is 1c no-voltage relay contact outputs. The contact capacity is
AC230V.0.2A and DC30V/0.3A.
Please make the RESET Input signal (pin No. 2-10) "Closed" for 0.1 seconds or more.
When I/O connector (CN2) is used for remote control and monitoring, use shielded cable to eliminate
EMC noise. Connect shield end to connector housing.
