P.69
[ NOTE ] It takes ten odd seconds until the flow has stabilized after you have
operated the N
2
gas selector valve.
DIP SW-A. No. 8 When dip switch-A No. 8 has been set to the REMOTE (Remote
Operation) position, it is possible to operate the Booster Pump (BP)
by selecting "AUTOMATIC Operation" or "START/STOP in
Response to External Signal Input."
DIP SW-B. No. 1 When you control MP speed by external signal, set dip switch-B
No.1 to ON.
DIP SW-B. No. 2 When you control BP speed by external signal , set dip
switch-B No.2 to ON.
DIP SW-B. No.6 Activate or inactive the special interface.
･ Set this to OFF to activate the interface (optional).
･ Set this to ON to inactivate the interface (default).
[ NOTE ] With this switch set to OFF, signal output from the control
signal connectors (CN-Z and CN-Y) that are directly
connected to the pump is prevented although that from the
special interface is allowed.
DIP SW-B. No.8 Locks or unlocks the currently selected operation status
display, which usually returns to the power display in 60
seconds.
DIP SW-C. No.1 This switch allows you to select "NORMAL OPEN" or
"NORMAL CLOSE" for PUMP N2 WARNING output.
PM10U
EBARA
CORPORATION
