EBS-230 Printer User's Manual
20080512#1.0
_______________________________________________________
9
´ Should the eyes or skin get irritated:
EYES rinse the eyes with running water for at least 15 minutes, then see your oculist,
SKIN wash the skin with water and soap.
2.2. Power Supply Requirements
Power Supply
The R230 cable distributor has a power pack with the following parameters:
Power supply (power pack integrated with
R230 cable distributor)
IN: 100-240 V~, 50-60 Hz / 0,66-0,34 A
OUT: 24V
, max. 1A
Maximum power consumption
0.58A for 7-nozzle printer,
0.91A for 16-nozzle printer.
NOTE:
• Take care while connecting a computer to the printing system (see section 2.5). Perform
the following operations to ensure safe connection:
a) Before connecting the R230 distributor cable to the computer disconnect power
supply from the printer with the distributor power-switch and wait a few seconds.
b) Connect the cable marked as PC/TERM to the computer and secure the male connector
against slipping out with attached lock screws.
c) Switch on power supply of the printer with the distributor power-switch.
ABSOLUTE EQUIPOTENTIALITY (equal potentials) OF THE PRINTER HOUSING AND THE
COMPUTER TO BE CONNECTED TO THE PRINTER is the prerequisite for safe connection
and proper operation (communication). Ideally, the metal printer housing should be connected
to earth at the same point where the outlet socket (neutral) to which the computer is
connected is. The efficiency of earthing should meet the requirements of the applicable
standards. The objective is to eliminate damage to electronic ports of the computer and printer
while connecting or disconnecting an interface cable to or from them.
• The printer and the computer must not be plugged into sockets of different ground
potentials.
• If the power network does not meet standard requirements, appropriate line-interference filters
or special interference-free connectors should be installed. This applies in particular to the
systems to/from which high loads, especially lagging ones, are connected/disconnected.
!
2.3. Installing the Printer
2.3.1. Standard and Optional Elements of the Printer
Some elements may not be part of a typical delivery or other elements which are not specified below
may be included, depending on your order.
The following elements are delivered most frequently as part of a typical system:
• EBS-230 printer ............................................................................................................ 1 unit
• Ink system with IMS module.................................................................................................. 1 unit
