EBS-230 Printer User's Manual
20080512#1.0
_____________________________________________________
11
4. Fix printer to horizontal or vertical mounting depending on needs.
5. Fix photo-detector to grip attached to printer mounting or to other place appropriate to the object
to be labelled.
6. Mount the distance holder on the main side of printer, in the opening, and on the side from which
the object to be labelled will move.
objects to be
labelled move in
this direction
distance holder
hole to install a
distance holder
photo-detector
photo-detector grip
Fig. 2.3.2.1.
Fixing elements of printer to standard mounting
