2. FUNCTIONAL AND TECHNICAL PARAMETERS
Transmission channels
*transparent, PSTN dialer required in a CP
ETH, GPRS, SMS, PSTN*
Backup server
YES (GPRS, SMS, ETH)
User notifications
SMS (5 phone numbers)
Communication watchdog
YES
Inputs
9 (NO/NC/EOL-NO/EOL-NC/DEOL-NO/DEOL-NC)
Partitions
2
Simulated PSTN Line
YES
Protocols supported on the phone input
SIA, ContactID
Control panel dialer bypass
NO (optional)
Voice gateway functions
NO (optional)
Outputs
2 (OC, max. load 100mA)
1 relay output (NO/NC, max. load 1A/30VDC or
0,5A/125VAC)
Output functions
- unavailable GSM signal or ETH channel
- GSM jamming (only for BGS2-W module)
- from server or through SMS
- incoming CLIP
- in reaction on events and inputs
RC Receiver: 434 MHz
NO (optional)
Max.number supported keyfobs
-
Power output +12V
YES (max. load 200mA)
Serial interface
RS232 / RS485 (lines: RxD, TxD, RTS, CTS)
transmission speed up to 115200bps
Alarm events buffer size
-
Quantity of system events stored in history
min. 5000
Event's timestamps
-
GPRS/SMS transmission security
AES encryption
Status LEDs
(functions)
4 LEDs (GSM signal level, device state, DTMF
communication)
Configuration
Remote: GPRS, SMS, CSD, ETHERNET cable via Web
Browser
Local: PC through RS232 (required cable: GD-PROG or
SP-PROG)
Remote firmware update
YES
Remote access to the control panels
NO (optional)
Phone line protection circuit
NO (optional)
Dual SIM
NO (optional)
Multiantenna steering output
NO (optional)
Supported modems
model EPX400-50: Cinterion BGS2-W (Quad-Band GSM:
850, 900, 1800, 1900 MHz)
model EPX400-60: Cinterion EHS6 (Five Bands UMTS:
800, 850, 900, 1900, 2100 MHz; Quad-Band GSM: 850,
900, 1800, 1900 MHz)
Ethernet
- 10BaseT/100Base-TX IEEE 802.3 compliant
- speed and duplex auto-negotiation
- auto-detection of correct cable connections
(cross/straight)
Power supply parameters
- PCB
Voltage supply
18V
AC
(acceptable: 16-20V
AC
)
Power consumption
DC (AKU)
(average / max)
100mA/170mA@13,8VDC*
* Measured with full charged battery, modem BGS2-W
Cinterion
120mA/205mA@13,8VDC*
* Measured with full charged battery, modem EHS6-A
Cinterion
Power consumption
AC (AC)
(average / max)
125mA/185mA@18VAC*
* Measured with full charged battery, modem BGS2-W
Cinterion
156mA/235mA@18VAC*
* Measured with full charged battery, modem EHS6-A
Cinterion
Power supply parameters
- PCB in EBS plastic casing
Voltage supply
230V
AC
(acceptable: 190-250V
AC
)
Power consumption
(average / max)
3W/13W@230V
AC
(recommended transformer 20W)
