11.3. DATA TRANSMISSION
During data transmission a green diode indicates data transmitting.
Description
LED Diodes
Green
Red
GPRS Transmission
SMS Transmission
11.4. RECEIVING OF DTMF DATA
STATUS LED (blue) and DTMF LED (yellow) indicate actual condition during
receiving data from a control panel.
Dioda LED
Signalling
STATUS
DTMF
(HandShake)
(KissOff)
6 digits of phone 16 digits ContactID
DTMF ERR OK STATUS
DTMF ERR OK STATUS
DTMF ERR OK STATUS
